Power your LED lighting with confidence using this 300W 24V DC Constant Voltage Triac Dimmable LED Driver, engineered for high-efficiency and smooth dimming control. With Triac dimming compatibility (supports Forward Phase, Reverse Phase, MLV & ELV dimmers), this driver ensures seamless, flicker-free lighting in residential, commercial, or industrial settings.

Built with an IP67-rated waterproof enclosure, this driver is perfect for both indoor and outdoor installations. Delivering a stable 24V DC output at 12.5A, it efficiently powers up to 300W of LED strips, signage, or lighting systems. With up to 88% efficiency and a power factor greater than 0.9, it reduces energy waste and maximizes performance.

Key Features:

Input Voltage: 200–240V AC

Output Voltage: 24V DC

Output Current: 12.5A

Total Power Output: 300W

Dimming Compatibility: Triac, MLV, ELV (forward/reverse phase)

Flicker-Free Output for visual comfort and camera-friendly lighting

High Efficiency: Up to 88%

Power Factor: > 0.9

IP67 Waterproof and Dustproof – ideal for outdoor use

Passive Cooling: Silent, fanless design via air convection

Protections: Short Circuit, Overload, Over Current, Over Temperature

Certifications: EN61347-1, EN61347-2-13

Dimensions: 276 x 78 x 47 mm

Warranty: 7 Years

Perfect for powering LED strip lights, architectural lighting, landscape lighting, or any constant voltage 24V LED application where reliable, dimmable, and weatherproof performance is a must.
